Features
88% energy efficiency
Heavy duty copper radiator
Pressure Relief Protection (to function effectively, the valve must be set to your water pressure)
Temperature controller included with a 10m cable
Inverter compatible
Compact design with a brushed aluminium cover
Weather proof exterior
Flame failure safety device
Ensures constant temperature when multiple outlets are used simultaneously
Automatic self diagnosis codes
Compatible with mixer taps
Technical Specifications
Max Gas Pressure – 2.8 kPa
Water Pressure – 25-500 kPa
Max Gas Consumption – 2.9 Kg / hour
Water Output (min/max) – 2.5L – 20L / min
Rated Electric Power – 45W
IP rate – IPX4
Rated Voltage – 240V / 60Hz
Rated Input – 40Kw
Unit Weight – 17.2 Kg
Packaged Weight – 18.7 Kg
Unit Size – 575 x 365 x 133 mm
Packaged Size – 740 x 430 x 220 mm
TYPE D
Install outdoors only
We recommend installing with a weather box (cover)
If a Gas Geyser is installed outside must be installed with weather box to protect the appliance against extreme weather and damage. The warranty on the appliance will be void if it is not installed with weather box when installed outdoors.
These boxes are designed to allow the hot air that is released by the unit to escape so that they do not over heat and cut out.
In extreme weather areas we recommend using a flue. If your geyser uses a flue then you will need a cover that has a flue roof.
